Industrial RO membrane elements

Industrial RO Membrane Elements

Industrial RO elements for power, pharmaceutical, food and beverage, and manufacturing applications.

Industrial performance

Listed industrial elements are tested at 6.9 or 10.3 bar (100 or 150 psi), with model-specific flow and rejection figures below. Selection is subject to feed-water qualification.

ScaleModel-specific flow

Resilience6.9–10.3 bar test pressure

SeriesBrackish Fouling Resistant Low Energy Compare models Get a quote

Brackish Water for Industrial Applications

Label colour: Indigo

Scroll horizontally to view all specifications.

Models

BW-28-365Formerly BW30-365	34.0 (365)	35.96 (9500)	99.5%	28	10.3 (150)
BW-34-365Formerly BW30-365	34.0 (365)	35.96 (9500)	99.5%	34	10.3 (150)
BW-28-400Formerly BW30-400	37.2 (400)	39.74 (10500)	99.5%	28	10.3 (150)
BW-34-400Formerly BW30-400	37.2 (400)	39.74 (10500)	99.5%	34	10.3 (150)
BW-28-440Formerly BW30-440	41.0 (440)	43.53 (11500)	99.5%	28	10.3 (150)
CP-34-8040Formerly CP-8040	37.2 (400)	39.74 (10500)	99.5%	34	10.3 (150)
HCM2-34-8040Formerly HCM2-8040	37.2 (400)	43.53 (11500)	98.5%	34	10.3 (150)

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

BW-28-365Formerly BW30-365

Active Area m² (ft²): 34.0 (365)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 35.96 (9500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 28

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

BW-34-365Formerly BW30-365

Active Area m² (ft²): 34.0 (365)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 35.96 (9500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 34

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

BW-28-400Formerly BW30-400

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 39.74 (10500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 28

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

BW-34-400Formerly BW30-400

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 39.74 (10500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 34

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

BW-28-440Formerly BW30-440

Active Area m² (ft²): 41.0 (440)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 28

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

CP-34-8040Formerly CP-8040

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 39.74 (10500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 34

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

HCM2-34-8040Formerly HCM2-8040

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 98.5%
Feed Spacer mil: 34

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

High Performance / Fouling Resistant

Label colour: Indigo

Scroll horizontally to view all specifications.

Models

HMBW-28-400Formerly TMBW30-400	37.2 (400)	43.53 (11500)	99.7%	28	10.3 (150)
HMBW-34-400Formerly TMBW30-400	37.2 (400)	43.53 (11500)	99.7%	34	10.3 (150)
HMBW-28-400-FRFormerly TMBW30-400-FR	37.2 (400)	43.53 (11500)	99.7%	28	10.3 (150)
HMBW-34-400-FRFormerly HMBW30-400-FR	37.2 (400)	43.53 (11500)	99.7%	34	10.3 (150)
HMBW-28-440-FRFormerly HMBW30-440-FR	41.0 (440)	47.88 (12650)	99.7%	28	10.3 (150)

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

HMBW-28-400Formerly TMBW30-400

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 99.7%
Feed Spacer mil: 28

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

HMBW-34-400Formerly TMBW30-400

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 99.7%
Feed Spacer mil: 34

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

HMBW-28-400-FRFormerly TMBW30-400-FR

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 99.7%
Feed Spacer mil: 28

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

HMBW-34-400-FRFormerly HMBW30-400-FR

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 99.7%
Feed Spacer mil: 34

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

HMBW-28-440-FRFormerly HMBW30-440-FR

Active Area m² (ft²): 41.0 (440)
Test pressure bar (psi): 10.3 (150)
Permeate Flow m³/d (GPD): 47.88 (12650)
Stabilized Salt Rejection %: 99.7%
Feed Spacer mil: 28

Test conditions: flow and rejection at 2,000 ppm NaCl, 25 °C (77 °F), 10.3 bar (150 psi), pH 7 (± 0.5)

Low Energy

Label colour: Teal

Scroll horizontally to view all specifications.

Models

BW-28-400-LEFormerly BW30-400-LE	37.2 (400)	43.53 (11500)	99.5%	28	6.9 (100)
BW-28-440-LEFormerly BW30-440-LE	41.0 (440)	49.21 (13000)	99.5%	28	6.9 (100)
HXLP-28-8040Formerly HXLP-8040	37.2 (400)	49.21 (13000)	99.7%	28	6.9 (100)
ES-34-8040Formerly ES-8040	37.2 (400)	45.42 (12000)	99.3%	34	6.9 (100)

Test conditions: flow and rejection at 1,500 ppm NaCl, 25 °C (77 °F), 6.9 bar (100 psi), pH 7 (± 0.5)

BW-28-400-LEFormerly BW30-400-LE

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 6.9 (100)
Permeate Flow m³/d (GPD): 43.53 (11500)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 28

Test conditions: flow and rejection at 1,500 ppm NaCl, 25 °C (77 °F), 6.9 bar (100 psi), pH 7 (± 0.5)

BW-28-440-LEFormerly BW30-440-LE

Active Area m² (ft²): 41.0 (440)
Test pressure bar (psi): 6.9 (100)
Permeate Flow m³/d (GPD): 49.21 (13000)
Stabilized Salt Rejection %: 99.5%
Feed Spacer mil: 28

Test conditions: flow and rejection at 1,500 ppm NaCl, 25 °C (77 °F), 6.9 bar (100 psi), pH 7 (± 0.5)

HXLP-28-8040Formerly HXLP-8040

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 6.9 (100)
Permeate Flow m³/d (GPD): 49.21 (13000)
Stabilized Salt Rejection %: 99.7%
Feed Spacer mil: 28

Test conditions: flow and rejection at 1,500 ppm NaCl, 25 °C (77 °F), 6.9 bar (100 psi), pH 7 (± 0.5)

ES-34-8040Formerly ES-8040

Active Area m² (ft²): 37.2 (400)
Test pressure bar (psi): 6.9 (100)
Permeate Flow m³/d (GPD): 45.42 (12000)
Stabilized Salt Rejection %: 99.3%
Feed Spacer mil: 34

Test conditions: flow and rejection at 1,500 ppm NaCl, 25 °C (77 °F), 6.9 bar (100 psi), pH 7 (± 0.5)
